ABAC DRY 60 Compressed Air Refrigerated Dryer (35 CFM, 16 Bar, Single Phase)

ABAC DRY 60 Compressed Air Refrigerated Dryer (35 CFM, 16 Bar, Single Phase) - 4102005872

• More economical distribution network
• Longer lifetime of your equipment and distribution network due to less wear
• Better productivity and lower maintenance costs thanks to less breakdowns
• Intelligent discharge silently getting rid of water
• Higher final product quality
• Increased reliability of your final tools/equipment
• Energy savings with lower pressure drops
• Easy dew point indicator reading
• C.F.M @ 3 degrees = 30 cfm
• C.F.M @ 5 degress = 35 cfm
• LED Display, dew, alarms, status
• Energy saving with lower pressure drops
• Inlet - Outlet 1/2 or 3/4 Bsp Male
• Digital Display
• No Loss Electric Drain

1 year standard warranty. If you purchase the dryer with the two filters, this extends the warranty on the dryer to 2 years.

The industry standard CFM rating is taken at 3 degrees C. Please ensure you check other sellers are using this figure and not the higher CFM rating taken at 5 degrees C.

ABAC provides refrigeration dryers to remove condensate and vapor so that dry, compressed air is produced in a continuous, cost-efficient way. Today’s compressed air generation process is not only a matter of producing air: purity and cleanliness have become fundamental features.

Atmospheric air that is sucked into a compressor always contains a certain amount of moisture, dust and oil aerosols. These substances can impair production results and even increase costs.

Based on an efficient and simple technology, refrigeration dryers represent the preferred solution for the majority of these applications. Teamed with our line filters, our customers are able to produce high quality air with reduced dew point, air purity to ISO 8573-1:2010.

Sizing a Dryer

You need to match the volume (cfm - l/min) of the compressor to the flow of the dryer.

Rule of thumb when selecting, you can go bigger, but never smaller, if the air volume is too large, the dryer cannot reduce the air temperature down
